Lọc Dầu Tách Nước Parker 500MA2, Lưu Lượng 227LPH

Lưu Lượng : 227LPH

Chất Liệu : Thép không gỉ

Dùng Cho Dầu Diesel

Racor - 500MA2 - Marine Fuel Water Separator -  2 Micron Filter

The Racor Marine Fuel Filter Water Separator Turbine Series is the most trusted fuel filter water separator on the market. The UL-approved assembly features a three-stage filtration system that effectively removes water and particulates from fuel, providing maximum protection of diesel engine components in marine applications where reliability is critical.

Filters can be mounted on-engine or remotely, and come with hand-operated fuel priming pumps, which allow for easy filter replacement and air purge. When it’s time for service, only the filter element is replaced—the bowl and drain plug are reused. Water-in-fuel (WIF) sensor upgrades are available for diesel applications to alert operators to drain accumulated water from the bowl.

All Marine Spin-on Series Fuel Filter Water Separators utilize Racor’s high-efficiency Aquabloc® engineered media, which repels water and removes solid contaminants from fuel at 98% efficiency of their micron rating. Depending on the product selected, three different micron ratings are available for purchase, including:

30 micron – Ideally suited as a pre-filter to protect downstream filters from excessive contamination. Extends the life of on-engine filters.

10 micron - Captures more contaminants than 30 micron elements, and is more effective at stopping water. Extends the life of the entire fuel system.

2 micron – Provides maximum water removal and filtration and is capable of protecting all modern injection systems, while greatly extending the life of difficult-to-service on-engine filters.

Technical Specifications

• Valve Type: n/a
• Flow Rate: 60 gph (227 lph)
• Connection Type: 3/4"-16 UNF-2B SAE Female
• Micron Rating: 98% @ 4 Micron
• Materials of Construction: Bowl - Clear Engineering Plastic with Stainless Steel Shield
• Water Sensor Option: n/a
• For Fluid Type: Diesel Fuel / B20
• Element Removal Clearance: 4 in / 10.2 cm inch
• Product Series: Cartridge FF/WS, Marine 500 Turbine
• Number of Ports: 2
• Materials of Construction: Powder Coated Aluminum Alloy
• Clean Pressure Drop: 0.02 bar, 0.34 psi
• Brand: Racor
• Mounting Type: Bracket Included
• Pump Type: None
• Maximum Continuous Pressure: 15 psi / 1.03 bar
• Number of Housings: 1
• Filter Element Type: Top loaded element cartridge with 2 Micron Aquabloc® Media
• Application: Marine fuel filtration
• Compatible Element: 2010 series
